Learn how to test a mechanical assembly and perform FEM analysis in FreeCAD with this complete step-by-step tutorial.
In this video, we’ll take a mechanical assembly and go through the process of checking its motion and behavior before moving into a detailed Finite Element Method (FEM) analysis. You’ll see how to prepare the model, apply the required constraints and loads, generate a mesh, run the analysis, and interpret the results.
What You’ll Learn
- How to simulate and test an assembly in FreeCAD
- How to check whether components move and work correctly
- How to assign material properties
- How to apply constraints and forces
- How to generate an FEM mesh
- How to run the simulation
- How to visualize stress and displacement results
- How to interpret FEM results in FreeCAD
